Embedded 4G Modem |
MDG100-0TU01
• 1x SIM (4FF)
• Mini-PCle
• GNSS
• 3.3V
• -30°C ~ 80°C
| ‧ | MDG100-0TU01 is designed as a socket modem with mini-PCIe form factor via USB 2.0 interface. This product has cellular capability with WCDMA and LTE Cat4 and also support GNSS receiver to get location information. It also has a hinge-up nano- SIM slot to offer a wide range usage for board without or with a SIM socket. The device offers OS-ready NIC interface (Windows / Linux / FreeBSD) and offer a friendly web-based GUI for parameter setting and status checking. |
| Device Interface | |
|---|---|
| Data Interface: | USB 2.0 / TTL UART(1.8V) on mini-PCIe |
| Power Input: | DC 3.3V via mini-PCIe |
| Antenna Con.: | 2*I-PEX LTE, 1*I-PEX GNSS |
| SIM: | 1* 4FF Hinge-up type for 1.8V / 3V SIM |
| Antenna Con.: | 2*I-PEX LTE, 1 I-PEX GNSS |
| RF Function | |
| Cellular: | WCDMA, LTE FDD / TDD cat 4. |
| GNSS: | GPS / GLONASS / BeiDou / Galileo / QZSS (Optional) |
| WAN & Uplink | |
| WAN: | NAT / Modem Mode Control Interface |
| Control Interface | |
| GUI: | Web-based Interface |
| AT Command: | 3GPP TS 27.007, 27.005 and enhanced AT commands |
| Environment | |
| OP/Store Temp.: | -30°C ~ 80°C; -40°C ~ 85°C |
| Humidity: | 10%~95% (non-condensing) |
| Dimension: | 51x31x5mm |
| Package Accessory | |
| 1*Device |
